Linx 7300FG

Know the product   Specification

The Linx 7900FG continuous ink jet food printer provides a flexible coding solution for printing onto food or pharmaceutical products, or farm packed eggs.
This small character food printer is designed to print with dedicated specialist food grade inks which meet FDA and EU regulations. It offers up to 3 lines of text, graphics and logos.
• No hidden costs
• Egg coder configuration - service intervals are matched to flock life
• IP55 rating as standard – reliable operation in barn environments
Take more control of your production line with Linx Insight®. This remote web interface allows you to monitor your Linx 7900 from a smart phone, plus download or upload messages from a PC. And Linx Insight is included with the printer at no extra cost. All you need is internet access on your PC or smart phone, and an ethernet connection to the printer.
Simple printer control
• Remote printer monitor and control with Linx Insight
• Quick code changes using a barcode scanner and QuickSwitch® software
• Easy transfer of messages between printers with a standard USB port or using Linx Insight
Lowest running costs
• Service interval for egg coding can be set to match flock life for reliable operation in barn environments
• Minimal parts changed at scheduled services – no expensive ink system assemblies to replace, so no hidden costs
Increased production uptime
• Automatic and thorough cleaning of the printhead and conduit at every shutdown. Linx’s unique FullFlush® system ensures reliable startups
• Fast mistake proof refills with the SureFill® system
Extra features – as standard
• Ethernet port
• 3 line printing
• Data Matrix 2D codes
• RS232 connectivity
• External single stage alarm output
• Connectivity for product detectors and shaft encoders

  Printing capability
• 3 lines of print as standard
• Maximum print speed of 6.28m/s (for single line of code)
• Print heights from 1.8mm to 10.5mm
• Data Matrix 2D codes
• Dynamic reverse/invert printing for traversing lines
Programming facilities
• Linx Insight remote printer control and status view
• Simple menu-driven WYSIWYG message creation and editing
• QuickSwitch® message selection and editing using a barcode scanner
• USB port for copy and back-up of message and printer settings, and for easy transfer of messages between printers
Physical characteristics
• Curved stainless steel casing with minimal dirt traps
• IP55 rating
• Weighs only 24kg
• No factory air required
